3.9 SCANNER UNIT
3.9.1 ARDF
1. Interface connector
2. ARDF [A] ( x2) Push the ARDF towards the front of the machine to align the
keyholes (not shown) of the ARDF base with the heads of the stud screws and
lift.
B004R535.WMF
[A]
[B]
