SERVICE PROGRAM MODE TABLES
B079/B082 5-70 SM
5.1.4 TEST PATTERN PRINTING: SP2-902
NOTE: Always print a test pattern to confirm correct operation of the machine.
1. Enter the SP mode and select SP2-902.
2. Press  or .
•  IPU Test Print
•  Test Pattern
3. Enter the number for the test pattern that you want to print and press OK. (See
the tables below.)
4. Press Copy Window to open the copy window and then select the settings for
the test print (paper size, etc.)
5. Press Start  twice. (Ignore the “Place Original” messages) to start the test
print.
6. Press SP Mode (highlighted) to return to the SP mode display.
Test Pattern Table (SP2-902-2: IPU Test Print)
No. Test Pattern No. Test Pattern
0 None 8 Grayscale (Horizontal) (8)
1 Vertical Line (1-dot) 9 Grayscale (Vertical) (8)
2 Horizontal Line (1-dot) 10 Cross Pattern (8)
3 Vertical Line (2-dot) 11 Cross Shape
4 Horizontal Line (2-dot) 12 Argyle Pattern
5 Alternate Dot Pattern 13 Cross Pattern (256)
6 Grid Pattern (1-dot) 14 Cross Pattern (64)
7 Vertical Stripes 15 Not used
