MECHANICAL COMPONENT LAYOUT
B543 2 SM
1.2 MECHANICAL COMPONENT LAYOUT
1. Relay Roller
2. Relay Sensor
3. Paper Feed Roller
4. Pick-up Roller
5. Paper End Sensor
6. Paper Tray
7. Separation Roller
A683V500.WMF
2
7
3
4
5
1
6
