3. REPLACEMENT AND ADJUSTMENT
3.1 REMOVAL
3.1.1 UPPER DOOR
1. Open the upper door [A].
2. Remove the lower hinge [B] ( x1).
3. Push up the upper door and remove it.
B546R579.WMF
[A]
[B]
