Ricoh B079 - Drive Layout

Large
Capacity Tray
B543
DRIVE LAYOUT
SM 5 B543
1.5 DRIVE LAYOUT
1. Relay Clutch
2. Paper Feed Clutch
3. LCT Motor
4. Tray Bottom Plate
5. Pick-up Roller
6. Tray Drive Belts
7. Lift Motor
8. Separation Roller
9. Paper Feed Roller
10. Relay Roller
A683V502.WMF
6
4
5
3
2
1
10
9
8
7
