Ricoh B079 - Drive Layout

Bridge Unit
B538
DRIVE LAYOUT
SM 3 B538
1.3 DRIVE LAYOUT
1. DF feed clutch
2. DF transport motor
3. 2nd transport roller
4. Exit roller
5. Separation roller
6. 1st transport roller
7. Original feed belt
8. Pick-up roller
B387V102.WMF
2
1
8
7
6
5
4
3
