5.6 DIP SWITCHES
Controller: DIP SW2
DIP SW No. ON OFF
1 IC Card Boot System ROM Boot
2
3
4
Keep at “OFF”
I/O Board: DIP SW101
DIP SW No. Function ON OFF
1 Copy Speed 35 cpm (180 mm/s) 45 cpm (230 mm/s)
2 Jam Detection
(see Note)
Off On
3 Engine Program
Recovery
On Off
4 Print Output for
Debugging
OFF (Do not change)
5 Factory Duplex
Function Check
OFF (Do not change)
JPN NA EUR China Taiwan Asia Korea
6
OFF ON OFF OFF ON ON OFF
7
OFF OFF ON OFF OFF ON ON
8
Destination
OFF OFF OFF ON ON OFF ON
NOTE: Disabling jam detection is effective only for the main machine (not for the
options).
