SERVICE PROGRAM MODE TABLES
SM 5-41 B079/B082
SP5-xxx: Mode
SP5 Mode Number Function and [Setting]
5024* mm/inch Display Selection Selects the unit of measurement.
After selection, turn the main power switch off and
on.
0: Europe/Asia 1: North America
0: mm, 1: inch
5044
Operation Panel Bit SW
DFU
5104*
A3/DLT Double Count Specifies whether the counter is doubled for
A3/DLT.
0: No
1: Yes
2: Counts once for A4 SEF fed from bypass tray.
If
is selected, the total counter and the current
user code counter count up twice when A3 or DLT
paper is used.
5106* 6* ADS Level Selection Selects the image density level used in ADS
mode.
[1~7 / 4 / 1 notch per step]
Example: If you set SP5-106-6 to “2”: Pressing the
Auto Image Density key toggles the display off
and manual notch 2 is selected.
Adjust this SP if the customer cannot attain clean
copies after performing automatic density
adjustment.
5112* Non-Standard Paper Selection Determines whether a non-standard paper size
can be initialized for copying or not.
0: No, 1: Yes
If is selected, a non-standard size can be input
using the UP mode.
5113* Selects the corresponding key for installed
devices such as a coin lock. Japan only
[0~5 / 0 / 1 step]
0 None.
1 Key card (RK3, RK4)
2 Key card (subtraction count setting)
3 Pre-paid card
4 Coin lock
5 MF key card (Peace) Japan only
11 MF key card (Increment)
Optional Counter Type
12 MF key card (Decrement)
5118* Disable Copying
DFU
5120* Mode Clear Opt. Counter
Removal
Clears all coin devices. Japan only
[0~2 / 0 / 1 step]
0: Normal reset.
1: Resets only when job finished or before job
begins.
2: Not normal reset.
5121* Counter Up Timing Determines whether the optional key counter
counts up at paper feed or at paper exit.
0: Feed, 1: Exit
The total counter is not affected by this SP mode.
