COVER REPLACEMENT
B542 12 SM
4. REPLACEMENT AND ADJUSTMENT
4.1 COVER REPLACEMENT
Right Cover
1. Remove the right cover [A] (2 screws).
Rear Cover
1. Remove the rear cover [B] (2 screws).
A682R500.WMF
[A]
[B]
