Ricoh B079 - Registration Roller Dust Blade

B079/B082 3-70 SM
3.16.9 REGISTRATION ROLLER DUST BLADE
1. Open the duplex unit and open the right door.
2. Remove the PCU. (! 3.11.1)
3. Remove the development unit [A].
4. Press the top of the blade [B] to unlock it and open it to the left.
5. Remove the dust blade [C] from the machine.
B079R910.WMF
B079R719.WMF
[B]
[C]
[A]
