Ricoh B079 - Original Feed Unit; Original Pick-Up Roller

ORIGINAL FEED UNIT
B541 2 SM
1.2 ORIGINAL FEED UNIT
1. Open the top cover.
2. Original feed unit [A]
Press it toward you on its shaft to
release and lift out.
1.3 ORIGINAL PICK-UP ROLLER
1. Original feed unit (! 1.2)
2. Pick-up roller [A] ( x1)
B351R101.WMF
B351R102.WMF
[A]
[A]
