Ricoh B079 - Folder Rollers

REMOVAL
SM 29 B546
Booklet
Finisher
B546
3.1.14 FOLDER ROLLERS
1. Remove the booklet unit
2. Remove the drive unit [A] ( x 4) [B], ( x 3), [C]).
3. Remove the front and rear tension springs [D].
B546R590.PC
X
B546R593.PCX
B546R591.PC
X
B546R592.PC
X
[A]
[D]
[D]
[B]
[C]
