Ricoh B079 - Ardf Output Check: Sp; Smc Print out Lists: Sp

Service
Tables
SERVICE PROGRAM MODE TABLES
SM 5-79 B079/B082
ARDF Output Check: SP6-008)
1. Open SP mode SP6-008.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Press On Twice to test the selected item. You cannot exit and close this display
until you click Off to switch off the output check currently executing.
No. Description
1 Feed Motor (Forward)
2 Feed Motor (Reverse)
3 Drive Motor (Forward)
4 Inverter Motor (Forward)
5 Inverter Motor (Reverse)
6 Feed Clutch
7 Inverter Solenoid
8 Pick-up Motor (Forward)
9 Pick-up Motor (Reverse)
5.1.7 SMC PRINT OUT LISTS: SP5-990
1. Open SP mode 5-990 and select the number corresponding to the list that you
wish to print.
SMC (System Parameter and Data Lists)
1
All Data List
2
SP Mode Data List
3
UP Mode Data List
4
Logging Data List
5
Self-Diagnostics Results List
7
NIB Summary
8
NetFile Application Log
21 Copy UP Mode List
22 Scanner SP Mode List
23 Scanner UP Mode List
2. Press “Execute” on the touch panel.
3. Select “Single Face” or “Both Face”.
4. After printing the list, press “Close” to return to the SP mode display.
5. Press Exit twice to close the SP Mode screen and return to copy mode.
