SERVICE PROGRAM MODE TABLES
B079/B082 5-78 SM
SP5-804 Output Check Table
No. Description No. Description
1 1st Paper Feed CL 45 Duplex Junction Gate Solenoid ()
2 2nd Paper Feed CL 46 Not used
3 3rd Paper Feed CL (PTU) 47 Relay Junction Gate Solenoid
4 4th Paper Feed CL (PTU) 48~49 Not used
5 By-pass Paper Feed CL 50 Tray Junction Gate Solenoid
6 LCT Paper Feed CL 51 Stapler Junction Gate Solenoid
52 Positioning Roller Solenoid (Finishers)
13 By-pass Pick-up Solenoid
14 LCT Pick-up Solenoid 56 Toner Bottle Motor
57 Transfer Belt Positioning Clutch
17 Transport Motor 1 (Finisher)
18 Transport Motor 2 (Finisher) 62 Quenching Lamp
19 Exit Motor (Finisher) 63 Charge Bias
20 Staple Motor (Finisher)
21 Punch Motor (Finisher) 67 Development Bias
68 Not used
25 LCT Motor 69 Transfer Belt Voltage
26 Bank Motor (Paper Tray Unit) 70 ID Sensor LED
27 Fusing/Feed-Out Motor
28 Main Motor 75 Exhaust Fan
29 Duplex Transport Motor 76 Elec. Equipment Cooling Fan (High Rev.)
30 Duplex Inverter Motor – Rev. 77 Elec. Equipment Cooling Fan (Low Rev.)
31 Duplex Inverter Motor – Fwd 78 Relay Unit Fan
32 Feed/Development Motor 79 Fusing Cooling Fan
85 Total Counter
35 Bank Relay Clutch (Paper
Tray Unit)
36 Relay Clutch
37 Not used 91 Not used
38 LCT Relay Clutch 92 Shift Tray Lift Motor (Finisher)
39 Registration Clutch 93 Jogger Motor (Finisher)
40 Development Clutch 94 Stapler Unit Motor (Finisher)
41 Exit Junction Gate Solenoid
(Upper Unit)
95 Stack Feed Out Motor (Finisher)
42 Duplex Junction Gate Solenoid
(Lower Unit)
96 Shift Motor (Finisher)
97 Stapler Rotation Motor (Two-Tray Finisher)
