DUPLEX UNIT
B079/B082 6-78 SM
6.13.2 DUPLEX DRIVE LAYOUT
1 Inverter roller 4 Transport motor
2 Inverter motor 5 Lower transport roller
3 Upper transport roller
B004D103.WMF
1
2
3
4
5
