Ricoh B079 - Drive Layout

DRIVE LAYOUT
SM 15 B541
Auto Reverse
Document
Feeder
B541
4.2 DRIVE LAYOUT
1 Feed motor 7 Inverter roller
2 Feed belt 8 Exit roller
3 Pick-up roller 9 Separation roller
4 Pick-up motor 10 Transport roller
5 Transport motor 11 Skew correction roller
6 Inverter motor
B351D102.WMF
1
2
3
4
5
6
7
8
9
10
11
