Ricoh B079 - Image Transfer and Paper Separation

Detailed
Descriptions
IMAGE TRANSFER AND PAPER SEPARATION
SM 6-81 B079/B082
6.14 IMAGE TRANSFER AND PAPER SEPARATION
6.14.1 OVERVIEW
1 Transfer belt 6 OPC
2 Drive roller 7 Pick-off pawls
3 Transfer belt cleaning blade 8 ID sensor
4 Transfer roller 9 Contact lever
5 Idle roller 10 Transfer belt contact clutch
B004D561.WMF
1
2
3
4
5
8
7
6
9
10
