Ricoh B079 - Side Fence Position Change

SIDE FENCE POSITION CHANGE
B543 14 SM
4.5 SIDE FENCE POSITION CHANGE
1. Push the down switch to lower the tray bottom plate until it reaches its lowest
position.
2. Remove the tray cover.
3. Remove the front and rear side fences [A, B] (1 screw each).
4. Install the side fences in the correct position.
A683R504.WMF
A4
[A]
[B]
LT
A4 → LT
