Ricoh B079 - Sp6-XXX: Peripherals

Service
Tables
SERVICE PROGRAM MODE TABLES
SM 5-59 B079/B082
SP5 Mode Number Function and [Setting]
7 NIB Summary
8 Print Net File Log
21 Copier User Program
22 Scanner SP
5990
23 Scanner User Program
SP6-xxx: Peripherals
SP6 Mode Number Function and [Setting]
DF Registration Adjustment Adjusts the side-to-side and leading edge
registration for simplex and duplex original
feeding in ARDF mode. Press  to toggle ±.
1* Side-to-side [–3 ~ +3 / 0.0 / 0.1 mm step]
2* Leading Edge (Thin Original) [–30 ~ +30 / 0.0 / 0.17 mm step]
3* Leading Edge (Duplex Front)
4* Leading Edge (Duplex Rear)
[–42 ~ +42 / 0.0 / 0.12 mm step]
6006*
5 Rear Edge Erase Sets the maximum setting allowed for rear edge
erase.
[–20 ~ +20 / -3 / 0.5 mm step]
ADF Input Check
1 Group 1
2 Group 2
Displays the signals received from sensors and
switches of the ARDF.( ! 5.1.5)
6007
3 Group 3
6008 ADF Output Check Switches on each electrical component (ARDF
motor, solenoid, etc.) of the ARDF for testing. (!
5.1.6)
DF Free Run
1 Duplex Mode
6009
2 Stamp Mode
Performs a free run with the ARDF for duplex and
stamp testing. Input the number for the item you
want to check, and then press On twice to start.
This is a general free run controlled from the
copier. For more detailed free run modes, see the
ARDF manual.
6010* DF Stamp Position Adjustment Adjusts the horizontal position of the stamp on the
scanned originals.
[–7~+7 / 0 / 0.5 mm steps]
Determines which original sizes are detected
when an original is detected that is larger than the
size assigned to the original size sensor. This
provides an alternate selection for detection,
other than that assigned with SP5131.
[0~1 / 0 / 1]
Japan
Bit 0 1
7 DLT SEF 11”x15”
North America
Bit 0 1
6 DLT SEF 11” x 15”
5 LT LEF US Exec LEF
4 LT SEF 8”x10” SEF
6016* Original Size Decision Priority
3 LG SEF F4 SEF
