Ricoh B079 - Lamp Stabilizer and Scanner Motor Drive Board

SCANNER UNIT
B079/B082 3-16 SM
3.9.9 LAMP STABILIZER AND SCANNER MOTOR DRIVE BOARD
1. ARDF (! 3.9.1)
2. Scanner rear cover (! 3.9.3)
3. Rear bracket [A] ( x5,  x2)
4. Lamp stabilizer [B] ( x2, standbys x3)
5. Scanner motor drive board [C] ( x2,  x2)
B004R960.WMF
[A]
[B]
[C]
