Ricoh B079 - Scanner Hp Sensor;Platen Cover Sensor

SCANNER UNIT
B079/B082 3-14 SM
3.9.7 SCANNER HP SENSOR/PLATEN COVER SENSOR
1. ARDF (! 3.9.1)
2. Scanner rear cover (! 3.9.3)
3. Scanner HP sensor bracket [A] ( x1)
4. Scanner HP sensor [B] ( x1)
5. Platen cover sensor [C] ( x1,  x1)
B004R107.WMF
[A]
[B]
[C]
