Ricoh B079 - Adjustment

REMOVAL
SM 35 B546
Booklet
Finisher
B546
Adjustment
1. Remove the booklet stapler cover [A] ( x 3).
2. Remove the three paper guides [B] ( x 1 ea.).
3. Loosen the two screws on each of the anvils [C].
B546R564.PCX
B546R565.PCX
B546R567.PCX
[A]
[B]
[C]
