Replacement
Adjustment
PRINTED CIRCUIT BOARDS
SM 3-77 B079/B082
3.19 PRINTED CIRCUIT BOARDS
3.19.1 HIGH VOLTAGE POWER SUPPLY
1. Rear upper cover (! 3.7.1)
2. High voltage power supply [A] ( x3, x6)
B004R965.WMF
[A]
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
