PAPER SENSOR REPLACEMENT
B544 6 SM
3.2 PAPER SENSOR REPLACEMENT
1. Remove the front cover.
2. Remove the exit guide plate [A] (1 screw).
3. Replace the paper sensor [B] (1 connector).
B376R501.WMF
[B]
[A]
