MECHANICAL COMPONENT LAYOUT
B542 2 SM
1.2 MECHANICAL COMPONENT LAYOUT
1. Upper Pick-up Roller
2. Upper Paper Feed Roller
3. Upper Relay Roller
4. Upper Separation Roller
5. Lower Relay Roller
6. Lower Paper Feed Roller
7. Lower Separation Roller
8. Lower Pick-up Roller
9. Lower Tray
10. Upper Tray
A682V500.WMF
10
9
8
5
6
7
4
3
2
1
