Replacement
Adjustment
DRIVE AREA
SM 3-75 B079/B082
3.18.2 MAIN MOTOR
1. Rear upper cover, high voltage power supply, flywheel (! 3.18.1)
2. Timing belt [A] x1
3. Bracket [B] ( x3)
4. Main motor [C] ( x2, x3)
B004R907.WMF
[B]
[A]
[C]
