Service
Tables
SERVICE PROGRAM MODE
SM 5-7 B079/B082
SP1 Mode Number Function and [Setting]
1106 2 Roller Ends
3 I/O Board Temp. at Power
On
Displays in degrees centigrade the internal
temperature of the machine when it was powered
on.
1109* Fusing Nip Band Check Checks the fusing nip band.
[0=Off, 1=On] (! 5.1.8)
1111*
Paper Reverse Timing
(Duplex)
Adjusts the timing for stopping the rotation of the
reverse roller after the trailing edge of the paper
passes the duplex entrance sensor.
[+5 ~ –5 / 0 mm / 1 mm step]
Adjust the timing if paper frequently jams at the
inverter gate in the duplex unit.
Motor Speed Adjustment Adjusts the speeds of the main motor,
feed/development motor, and fusing exit motor.
1 Main Motor
2 Feed/Development Motor
1801
3 Fusing/Exit Motor
[-4 ~ +4 / 0 / 0.15%]
Each step decreases or increases motor speed in
0.15% increments
