SERVICE PROGRAM MODE TABLES
SM 5-19 B079/B082
SP4 Mode Number Function and [Setting]
4303* APS A5/LT Size Detection Determines whether the original is A5/HLT size
when the APS sensor does not detect the original
size.
0: not detected, 1: A5 length 5½ x 8½
If 1 is selected, paper sizes that cannot be
detected are regarded as A5 SEF. If 0 is
selected, “Cannot detect original size” will be
displayed.
4305* 8K/16K Detection Selects whether or not the copier determines that
the original is 8K/16K size when the APS sensor
does not detect the original size.
This SP is intended for use with 8K/16K Chinese
paper sizes only.
For China/Taiwan area:
[0,1 /0/1]
0: 8k/16k not detected – Non-standard size
1: 8K, 16K paper size detect enabled
Other areas:
[0,1 /0/1]
0: 8k/16k not detected - Non-standard size
1: 8k/16k not detected - Non-standard size
4307* APS Sensor Output Display Determines whether or not the original size is
detected while the exposure lamp lights during
initialization.
0 ~ 1 /1 / 1 step
0: Original size detection at power on disabled.
1: Original size detection at power on enabled.
1
Flag Display
DFU
2
Start
DFU
4428
3
Flag Reset
DFU
SBU Settings
DFU
22* A/D Standard Voltage in AE
Mode
DFU
23* BK Adjustment
DFU
24* EO Adjustment
DFU
26* Range Adjustment
DFU
27* Gain Adjustment – Ech
DFU
28* Gain Adjustment – Och
DFU
29* Apli. Dummy Range
Adjustment
DFU
30* Apli. Range Adjustment
DFU
31* Apli. Gain Adjustment – Ech
DFU
32* Apli. Gain Adjustment –
Och
DFU
33
Dummy Gain Adjustment –
Ech
DFU
4901*
34
Dummy Gain Adjustment –
Och
DFU
