USING THE DEBUG LOG
SM 5-101 B079/B082
Service
Tables
The following keys can be specified. The initials in parentheses indicate the names
of the modules.
SP5859 COPY FAX PRINTER SCANNER WEB
001 2222 (SCS
002 2223 (SRM)
003 256 (IMH)
004 1000 (ECS)
005 1025 (MCS)
006 4848 (COPY) 4846 (FAX) 4400 (GPS) 5375 (Scan) 5682 (NFA)
007 2224 (BCU) 1538 (FCS) 4500 (PDL) 5682 (NFA) 6600 (WebDB)
008 6016 (RFAX) 4500 (GPS-PM) 3000 (UCS) 3300 (PTS)
009 6017 (WEB) 2000 (NCS) 2000 (NCS) 6666 (WebSys)
010 2000 (NCS) 2224 (BCU) 2000 (NCS)
Key to Acronyms
ECS: Engine Control Service
FCS: Fax Control Service
GPS: GW Print Service
GSP-PM: GW Print Service – Print Module
IMH: Image Memory Handler
MCS: Memory Control Service
NCS: Network Control Service
NFA: Net File Application
PDL: Printer Design Language
PTS: Print Server
RFAX: Remote Fax
SCS: System Control Service
SRM: System Resource Management
WebDB: Web Document Box (Document Server)
Note the following restrictions on these settings:
• Only one of the 10 SP codes above can be selected for one key.
• You cannot mix settings for the groups for 005~010. For example, if you want
to create a PRINTER debug log you must select all 9 available selections
(001~009 in the PRINTER column of the Table above), and for a FAX debug
log you must select all 10 selections (001~010 in the FAX column of the Table
above.)
