BOARD STRUCTURE
SM 6-9 B079/B082
HDD: A 3.5" HDD (more than 20 GB) can be connected using an IDE I/F. The hard
disk is partitioned as shown below.
Partition Size Function Power OFF Comment
File System 1 500 MB
Downloaded
fonts, forms.
Remains
File System 2 500 MB
Job spooling
area.
Erased
File System 3 2000 MB Work data area Remains
Used for document server
application.
Image TMP 5200 MB
Collation,
sample print,
protected print.
Erased
Image LS*
1
7800 MB
Document
server, local
storage archive
Remains
Storage capacity
(Max. *
2
):
2500 pp. (Copy)
9000 pp. (Print/ Fax/
Scanner)
Image Area
Management
100MB
Stores image
area information
Remains
Job Log 20 MB Job log. Remains
Others 3362 MB
Total 20 GB
Remains
*1
:
When an application uses an image page, first it uses the Image LS area. If
this area is in use and not available, then it uses the Image TMP area.
*2
:
These areas are used for applications to store copy, print, fax, and scanned
pages. The actual number of pages that can be stored differs depending on the
content of the document and the scanning resolution.
