BOOKLET UNIT GATE MECHANISM
SM 11 B546
Booklet
Finisher
B546
The following tables show the relation between paper sizes and solenoids/sensors:
A3, 11" x 17" B4, 11" x 14" A4, 8
1/2" x 11"
1st Solenoid (Gate) OFF (Opened) ON (Closed) ON (Closed)
2nd Solenoid (Gate) OFF (Opened) OFF (Opened) ON (Closed)
A3, 11" x 17" B4, 11" x 14" A4, 8
1/2" x 11"
Trailing Edge Sensor 1 ON ON ON
Trailing Edge Sensor 2 OFF ON ON
Trailing Edge Sensor 3 OFF OFF ON
