ELECTRICAL COMPONENT DESCRIPTION
B408 14 SM
Symbol Name Function Index No.
SOL3
Positioning
Roller
Moves the positioning roller.
13
Switches
SW1
Lower Tray
Upper Limit
Detects when the lower tray is at its upper limit
position.
9
SW2
Front Door
Safety
Cuts the dc power when the front door is
opened.
6
SW3
Upper Cover Cuts the dc power when the upper cover is
opened.
1
PCBs
PCB1
Main Controls the finisher and communicates with the
copier/printer.
28
To Next Page
