IEEE 1394 FIREWIRE (G336)
SM 11 B548
Printer Option
B548
UP Mode Settings for IEEE 1394
Enter the UP mode and follow the procedure below to perform the initial interface
settings for IEEE 1394. These settings take effect every time the machine is
powered on.
1. Press User Tools/Counter.
2. On the touch panel, press System Settings.
3. Press Interface Settings.
4. Press the key and enter the following settings:
• IP Address
• Subnet Mask
• IP Over 1394. Enable or disable this setting as required. This setting enables
IP Over 1394 as the default setting for the printing method.
• SCSI Print. Enable or disable this setting as required. This setting enables
SCSI Print as the default setting for the printing method.
• SCSI Print Bi-directional. Switch bi-directional printing on or off for SCSI print.
SP Mode Settings for IEEE 1394
The following SP commands can be set for IEEE 1394.
SP No. Name Function
5839 004 Device Name Sets the names for all the physical devices connected to
the IEEE 1394 firewire network.
5839 007 Cycle Master Enables or disables cycle master function of the IEEE 1394
standard bus.
5839 008 BCR Mode Sets the BCR (Broadcast Channel Register) setting for the
Auto Node operation for the standard IEEE1394 bus for
when IRM is not in use. Three settings are available: 00,
01, 11.
5839 009 IRM 1394a Check Determines whether an IRM check for IEEE 1394 is
conducted for the Auto Node when IRM is not used.
5839 010 Unique ID Enables the “Node_Unique_Id” setting for enumeration on
the standard IEEE 1394 bus.
5839 011 Logout Determines how successive initiator login in requests are
handled during login in for SBP-2.
5839 012 Login Enables or disables exclusive login for SBP-2.
5839 013 Login MAX Sets the limit for the number of logins for SBP-2. Range: 1
~ 62.
