Installation
TWO-TRAY FINISHER INSTALLATION (B545)
SM 1-39 B079/B082
9. Install two trays [A] ( x 1 each).
10. Connect the finisher cable [B] to the main machine below the right, rear handle.
11. Turn on the main switch and check the finisher operation.
B545I103.WMFF
B545I106.WMF
[A]
[B]
