Ricoh IM C300 - Entrance Sensor (S45)

Internal Finisher (IM C400SRF Only)
SM 4-97 D0CA/D0C9/D0C8/D0CB
Replacement
&
Adjustment
5. Remove the jogger fence HP sensor bracket [A] ( x 1).
6. Remove the jogger fence HP sensor (S41) [A] ( x 1, x 1).
4.8.13 ENTRANCE SENSOR (S45)
1. Remove the internal finisher. (Removing the Internal Finisher)
2. Remove the paper exit upper cover [A].
