2.15 OPTIONAL COUNTER INTERFACE UNIT TYPE M12
(B870-21)
2.15.1 ACCESSORY CHECK
No. Description Q’ty
1 Counter interface board 1
2 Harness 1
3 Stud 4
4 Clamp 1
5 Harness band 1
6 Screws (Not used) 4
7 Screws (Not used) 2
- Caution Chart 1
2.15.2 INSTALLATION PROCEDURE
• Turn OFF the main power and unplug the power cord from the wall socket. If the main
power is not turned OFF before installing, an electric shock or malfunction might occur.
1. Remove the rear cover. (Rear Cover)
