Machine Overview
SM 7-11 D0CA/D0C9/D0C8/D0CB
Internal Finisher
Callout Item Callout Item
1 Main Board (PCB25) 5 Stopper Solenoid (SOL3)
2 Tray Lift Motor (M22) 6 Exit Guide Plate Motor (M21)
3 Tray Lower Limit Sensor (S39) 7 Interlock Switch (SW3)
4 Remaining paper sensor (S40) - -
Callout Item Callout Item
1 Gathering Roller HP Sensor (S38) 5 Paper Exit Sensor (S43)
2 Gathering Roller Motor (M18) 6 Entrance Sensor (S45)
3 Jogger Motor (M20) 7 Staple Tray Paper Sensor (S42)
4 Jogger Fence HP Sensor (S41) - -
