Special Tool s
SM 4-7 D0CA/D0C9/D0C8/D0CB
&
Adjustment
Do NOT apply grease on the tips of the studs.
Maximum minimum
0.02g 0.004g
The Images of the maximum amount [A] and minimum amount [B]
• Drive Unit Fusing Drive Gear
• Drive Unit Fusing Drive Brackets
Drive: Transport Drive Unit: IM C300 series
Description Description
[A] Transport Gear 01 [D] Transport Gear 04
[B] Transport Gear 02 [E] Registration Clutch (CL8)
[C] Transport Gear 03
Transport Drive Bracket
Lubrication parts Lubrication spots
