D0CA/D0C9/D0C8/D0CB 4-8 SM
Lubrication parts Lubrication spots
4 studs 4 spots
4 sliding parts 4 spots
Do NOT apply grease on the tips of the studs.
• Output Gear 01
Lubrication parts Lubrication spots
1 gear 1 spot
• Output Gear 02
Lubrication parts Lubrication spots
2 gears 1 spot
• Paper Feed Roller Axis
Lubrication parts Lubrication spots
1 axis 1 spot
