Controller Options
SM 2-139 D0CA/D0C9/D0C8/D0CB
2. Install the interface board [A] into the slot. (Knob-screw × 2 [B])
When inserting into the slot, push the interface board until it is inserted properly.
3. Turn ON the power.
4. Make sure that the machine can recognize the option (see Check All Connections at the
end of this section).
The customer should keep the removed slot cover.
2.20.3 FILE FORMAT CONVERTER TYPE M19 (D3BR-04)
Component Check
No. Description Q’ty
1 File Format Converter 1
2 Notes for Users 1
