Paper Exit
SM 4-195 D0CA/D0C9/D0C8/D0CB
&
Adjustment
4. Remove the anti-static cover [A] from the paper exit sensor (S7).
Junction Gate Solenoid (SOL1)
1. Remove the paper exit unit. (Paper Exit Unit)
2. Remove the junction gate solenoid (SOL1) [A] with the bracket.
3. Remove the bracket from the junction gate solenoid (SOL1) [A].
To Next Page
