Electrical Component Defects
D0CA/D0C9/D0C8/D0CB 6-160 SM
6.14 ELECTRICAL COMPONENT DEFECTS
6.14.1 SENSORS
No. Sensor Name/
Sensor Board
Name
Activ
e
CN No./
Pin No.
Conditi
on
Symptom
S1 Duplex entrance
sensor (S1)
L CN523/15 Open Jam Z (Jam
26)
Shorted Jam Z (Jam
18)
S2 Duplex exit sensor
(S2)
L CN523/25 Open Jam Z (Jam
25)
Shorted Jam Z
S3 Fusing entrance
sensor (S3)
L CN523/22 Open Jam B (Jam
18)
Shorted Jam C
S4 Bypass tray lift
sensor (S4)
H CN523/11 Open SC508
Shorted
S5 Bypass paper
width sensor (S5)
L CN523/2 Open A4/LT size is
not detected.
Shorted A4/LT size is
detected.
S6 Paper end sensor
(bypass) (S6)
L CN523/5 Open Paper is
detected on
the by-pass
tray when no
paper is set.
Shorted Paper is not
detected on
the by-pass
tray when
paper is set.
S7 Paper exit sensor
(S7)
L CN525/11 Open Jam C (Jam
20)
Shorted Jam C (Jam
60)
S8 Fusing exit sensor L CN525/8 Open Jam C (Jam

Ricoh IM C300 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.2 s
Time to first page (color, normal)	8.6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP
Internal memory	2048 MB
Compatible memory cards	SD
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Control type	Touch
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1200 W
Power consumption (ready)	50.6 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.34 kWh/week
Scan to	E-mail, FTP, Memory Card, Network folder, USB
Scanner type	Flatbed & ADF scanner
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Faxing	No
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	- pages per month
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	2000 sheets
Total number of input trays	1
Maximum number of input trays	3

Weight and Dimensions

Depth	561 mm
Width	498 mm
Height	510 mm
Weight	47000 g
