Paper Feed
D0CA/D0C9/D0C8/D0CB 4-176 SM
Registration Sensor (S32)
1. Open the right door.
• If you find paper dust in the registration section when you open the duplex unit,
remove the dust. Otherwise, the dust can cause lines on the image.
2. Remove the sensor cover [A].
3. Remove the sensor bracket [A].
4. Remove the registration sensor (S32) [A]. (Hook × 4)
To Next Page
