UP/SP Data Import/Export
SM 5-65 D0CA/D0C9/D0C8/D0CB
Maintenance
6. Select an encryption setting.
Unique If you want to apply the unique information to the target
machine, select the "Unique" key.
Refer to the above
information.
Encryption If an encrypted file is selected as the import file, this
setting is required.
7. Press [Execute].
8. Press [OK].
• If data export/import fails, the details of the error can be viewed in the log.
5.13.3 POSSIBLE SOLUTIONS FOR IMPORT/EXPORT PROBLEMS
The access log file is created when export/import is executed. The file is stored in the same
location as the exported device setting information file.
If an error occurs, check the log's result code in the access log file first. Values other than 0
indicate that an error occurred.
The result code will appear in the circled area illustrated below.
- Example of a log file
If you cannot solve the problem or do not know how to solve it after checking the code, note
down the error log entry, then contact your supervisor.
Result Code Cause Solutions
2 (INVALID
REQUEST)
A file import was attempted between
different models or machines with
different device configurations.
Import files exported from the same
model with the same device
configurations.
4 (INVALID
OUTPUT DIR)
Failed to write the device
information to the destination
device.
Check whether the destination device is
operating normally.
7( MODULE An unexpected error occurred Switch the power off and then back on,
