RTC6 boards
Doc. Rev. 1.0.21 en-US
7 Basic Functions for Scan Head Control and Laser Control
209
innovators for industry
61
Pulse Synchronization Mode. For more information, see text.
4
3
2
1
t [µs]
2010
0
1
1
1
0
0
0
Legend
1. Clock signal of the laser@DIGITAL IN1 pin.
2. Pulse Synchronization Mode disabled: LASER1 pulses@LASER1 pin, not synchronized with 1.
3. Pulse Synchronization Mode enabled: LASER1 pulses@LASER1 pin, synchronized with 1.
4. Change of HalfPeriod, for example, due to a set_laser_pulses call.
Delay from set_laser_pulse_sync
