Scanlab RTC6 PCIe Board - Load_Program_File

RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
509
innovators for industry
Ctrl Command load_program_file
Function • Resets the RTC6 (Software Reset)
• Initializes the RTC6 List Memory
• Performs a DSP memory check
• Loads RTC6RBF.rbf
• Loads RTC6OUT.out (with RTC6 Ethernet Boards, RTC6ETH.out is loaded instead
• Loads RTC6DAT.dat
• Starts the DSP
Call ErrorNo = load_program_file( Path )
Parameters Path Path name of the directory, where RTC6OUT.out , RTC6RBF.rbf and RTC6DAT.dat
are. As a pointer to a \0-terminated string.
Result Error code.
As an unsigned 32-bit value.
0 Success.
1 Not used.
2 The board is not running. If a renewed call does not bring success, then a
Hardware Reset is necessary.
3 RTC6DAT.dat or RTC6RBF.rbf not found.
4 Not used.
5 Not enough Windows memory.
6 Another user program has already acquired the board.
7 Version error: RTC6 DLL version, RTC6RBF.rbf version and
RTC6OUT.out / RTC6ETH.out version are not compatible with each other.
8 RTC6 board driver not found.
9 Loading of RTC6OUT.out or RTC6ETH.out failed or has incorrect format or other
error.
10 Not used.
11 FPGA firmware error: loading of RTC6RBF.rbf failed.
12 Error opening/reading RTC6DAT.dat .
13 Not used.
14 DSP memory error (external).
15 Verify memory error.
16 DSP memory error (internal).
17 Ethernet error. See eth_get_last_error and eth_get_error.
18 Only RTC6 Ethernet Board: NAND Memory error.
