Ctrl Command set_defocus_offset
Function Defines an offset in addition to the focus shift (see set_defocus) for all 3D outputs.
Restriction Like set_defocus.
Call set_defocus_offset( Shift )
Parameters Shift Like set_defocus.
Comments • set_defocus_offset has the same effect as set_defocus.
• set_defocus_offset enables setting a global defocus shift that is not overwritten by
parameterized commands such as para_mark_abs, see set_vector_control( Ctrl = 7).
• set_defocus_offset shift :
– Works additively to set_defocus
– Cannot be used as a control parameter for “vector-controlled laser control”
– Cannot be recorded via Signal 32 with set_trigger/set_trigger4/set_trigger8
– Is taken into account by get_z_distance, get_galvo_controls and the back
transformation (transform, get_transform/get_transform_offset)
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for Shift by 16.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility Mode, the RTC6 multiplies the specified value for Shift by 16.
Version info Available as of DLL 609, OUT 609, RBF 614.
References set_defocus, set_defocus_
offset_list
