10 RTC6 Commands
383
innovators for industry
Ctrl Command eth_set_static_ip
Function Writes a static IP address, a subnet mask and also a gateway address onto the
RTC6 Ethernet Board.
Call Result = eth_set_static_ip( Ip, NetMask, Gateway )
Parameters Ip Static IP address in Big Endian byte order.
As an unsigned 32-bit value.
NetMask Subnet mask in Big Endian byte order.
As an unsigned 32-bit value.
Gateway Address of the gateway in Big Endian byte order.
As an unsigned 32-bit value.
Result Error code.
As an unsigned 32-bit value.
0: Success: OK.
1: Error: No access to the RTC6 Ethernet Board.
get_last_error return code RTC6_ACCESS_DENIED .
2: Error: No RTC6 Ethernet Board.
get_last_error return code RTC6_TYPE_REJECTED .
3: Error: Programming the Flash Memory is not possible.
The RTC6 Ethernet Board is possibly busy.
get_last_error return code RTC6_BUSY or RTC6_FLASH_ERROR .
Comments • Prerequisites for eth_set_static_ip:
– No list must currently be executed on the RTC6 Ethernet Board.
– The RTC6 Ethernet Board must be entered in the RTC6 board management.
– The RTC6 Ethernet Board must have been acquired.
• If no gateway is to be used, then Gateway must be set to 0.
• To convert from usual dotted decimal notation to Big Endian byte order,
eth_convert_string_to_ip can be used. See also Chapter 16.5.1 ”Notes on Working
with IP Addresses”, page 904.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 606, OUT 606, RBF 611.
References eth_convert_string_to_ip, eth_get_static_ip
