10 RTC6 Commands
479
innovators for industry
Undelayed
Short List
Command
list_call_cond
Function Conditional subroutine call: list_call_abs_cond executes list_call( Pos ), if the current
IOvalue at the EXTENSION 1 socket connector’s 16-bit digital input port meets the
following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ).
Otherwise, the directly following list command is immediately executed.
Call list_call_cond( Mask1, Mask0, Pos )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 See Mask1 .
Pos Absolute jump address [0…(2
23
–1)].
As an unsigned 32-bit value.
Comments • See list_call.
• See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
RTC4RTC6 Basically unchanged functionality (see list_call).
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References list_call
