Ctrl Command set_firstpulse_killer
Function Sets the length of the FirstPulseKiller signal for a YAG laser.
Call set_firstpulse_killer( Length )
Parameters Length Length of the FirstPulseKiller signal.
As an unsigned 32-bit value.
1 bit equals 1/64 µs.
Allowed value range: [0…+(2
26
–1)].
Out-of-range values are clipped to the boundary values.
Comments • The clock frequency connected to the FirstPulseKiller signal is 64 MHz.
1 bit equals 1/64 µs.
• The signal level is set by set_laser_control.
• For YAG Mode 2, the Q-Switch delay is also correspondingly altered, see Section
”Differences Between the YAG Modes”, page 190.
• In CO
2
Mode, set_firstpulse_killer has no effect.
• The laser mode is set by set_laser_mode, see Chapter 7.4 ”Laser Control”, page 184.
• Q-Switch pulse length and Q-Switch period can be set by set_laser_pulses_ctrl,
set_laser_pulses or set_laser_timing.
RTC4RTC6 Basically unchanged functionality. In addition: increased value range.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value by 8.
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_laser_mode, set_laser_timing
Undelayed
Short List
Command
set_firstpulse_killer_list
Function Like set_firstpulse_killer, but a list command.
Call set_firstpulse_killer_list( Length )
Parameters Length Like set_firstpulse_killer.
RTC4RTC6 As set_firstpulse_killer.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_firstpulse_killer
